Tizona Road Rim Brakes
    Tizona

    Tizona Road Rim Brakes

    Reference: RoadRim
    $8,400.00
    Tax included

    The Tizona Road Bike with rim brakes is our lightest model, featuring Shimano Ultegra R8100 2x12, Tizona Carbon components, and DT Swiss P1800 Spline wheels. Available in sizes S, M, and L.

    Size Guide
    Size Guide
    BIKE SIZE Road Frame
    Frame Size S M L
    A. Stack 523 547 577
    B. Reach 340 386 398
    C. Head tube angle 73 73 73.5
    D. Head Tube 115 140 170
    F. Seat Tube Angle 74 74 73
    G. Seat Tube 515 540 560
    H. Top Tube 522 539 562
    I. Effective Top Tube 530 549 575
    P. Chain Stay 410 410 410
    N. BB Drop 72 72 71
    BIKE SIZE Gravel Frame

    Frame Size S M L
    A. Stack 539 567 589
    B. Reach 372 377 390
    C. Head tube angle 71.5 71.5 72
    D. Head Tube 130 160 180
    F. Seat Tube Angle 73.5 73.5 73
    G. Seat Tube 495 515 540
    H. Top Tube 511 530 559
    I. Effective Top Tube 520 545 570
    P. Chain Stay 435 435 435
    N. BB Drop 67 67 65

    How to Choose Your Bike Size

    To ensure optimal comfort and performance, follow these steps to measure yourself for the correct bike size. Use a flexible measuring tape and take each measurement carefully.

    1. Height:

    Stand against a wall with your feet together and back straight. Have someone measure from the floor to the top of your head. Make sure you're standing flat-footed. This will give a general idea of your bike frame size.

    2. Inseam:

    Stand barefoot with your feet slightly apart. Place a book between your legs and push it up as far as comfortable, simulating the bike seat. Have someone measure from the top of the book to the floor. This measurement helps in determining your standover height, ensuring that you can comfortably straddle the bike.

    3. Arm Length:

    Extend one arm outward, parallel to the floor. Measure from your collarbone (just above the shoulder) to the middle of your palm. This measurement helps in adjusting the reach to the handlebars for comfort.

    4. Torso Length:

    Stand up straight and measure from the base of your neck (at the collarbone) to your groin. This helps in determining the bike's top tube length, making sure you have the right reach.

    5. Standover Height:

    This is the distance from the ground to the top of the bike's top tube. Ensure you have at least 1-2 inches of clearance when standing over the top tube with both feet flat on the ground.

    • Small
    • Medium
    • Large
    Quantity

    reassuarence-customicon

    Security policy

    reassuarence-customicon

    Delivery policy

    reassuarence-customicon

    Return policy

    Experience the ultimate in-road cycling with the Tizona Road Bike featuring rim brakes.

    This model is the lightest in our lineup, designed for speed and agility. Equipped with the Shimano Ultegra R8100 2x12 and Rim Brake Di2, it offers precise shifting and reliable performance. The Tizona Carbon Road Fork and Seatpost ensure a smooth ride, while the Tizona Alloy 90mm Stem and Tizona Carbon Aero Handlebar provide superior control and aerodynamics. The Selle Italia Novus Saddle offers comfort on long rides, and the DT Swiss P1800 Spline Wheelset with Schwalbe One 700x25c tyres deliver exceptional traction and speed.

    Available in sizes S, M, and L, this bike is perfect for riders seeking a high-performance road cycling experience.

    Product Details

    5 Items

    Data sheet

    Stem
    90m
    Tyre Clearance
    700x25C
